Infrared (IR) technology is widely used in the oil and gas industry as an inspection tool for condition monitoring and predictive maintenance. It is advantageous over traditional visual inspection and other tools because infrared technology does not have to be in contact with the equipment being monitored.
IR thermography is a form of nondestructive testing that measures temperature variances of a component as heat (i.e. thermal radiation) flows through, from, or to that component. IR thermography is also generically known as IR testing, thermal testing, thermal imaging, and IR thermometry.
Thermal radiation is directly related to changes in temperature. In other words, as a component changes temperature, the amount of radiation emitted changes. Since this type of radiation is a form of electromagnetic waves that cannot be seen with the human eye, components have to be analyzed using infrared cameras. Infrared cameras are able to detect and display emitted, reflected, and transmitted infrared energy from an component. The thermal image can then be analyzed to obtain a temperature reading for the component.
The purpose of mapping temperature levels and variances of a component is to detect any hot spots where equipment may weaken or fail. IR thermography is also capable of detecting corrosion damage, delaminations, voids, inclusions, and other flaws that affect heat transfer. However, in order to detect these anomalies, there must be sufficient temperature difference between the component and its surroundings.

Fundamental IR Thermography Concepts
  • Emissivity refers to a material’s ability to emit infrared energy. Emissivity is expressed as a value between 0 and 1 where 0 describes a perfect mirror surface and 1 describes a blackbody. For example, a material with an emissivity value of 0.95 absorbs and emits 95% of infrared radiation and reflects 5% of the surrounding radiation.
  • Reflectance refers to the amount of light reflected from the surface of a material.
  • Transmittance is a material’s ability to transmit thermal energy (i.e. heat) from a component being tested to an infrared camera. For example, plastics are transmissive while metals are opaque and are not transmissive.

Heat vs Temperature

These terms are commonly used interchangeably. Although they are related, they have very distinct meanings.

  • Heat is a measure of the total energy of molecular motion of an object and is dependant on the size of the object. Heat also describes how thermal energy transfers from one object to another or its surroundings.
  • Temperature refers to an object’s average energy of molecular motion and, unlike heat, can be measured directly. Temperature does not depend on the size of the object.

Heat Transfer describes the phenomenon of thermal energy transferring from a hotter temperature region to a colder temperature region.
Heat Transfer Mechanisms — Heat can transfer in three ways:

  • Conduction is the transfer of heat between two solids.
  • Convection is the transfer of heat through liquids and gases.
  • Radiation is the transfer of heat through electromagnetic waves.

Thermography Considerations


Component Factors

In terms of equipment being tested, operators and inspectors should have working knowledge about the:

  • Equipment and process
  • Material type (e.g. steel, stainless steel, etc.)
  • Material properties (e.g. thermal diffusivity)
  • Thickness and geometry of the component
  • Emissivity of the material
Anomaly Factors

If infrared technology is being used to detect flaws, knowledge about the size, depth, and orientation of the anomaly must be known.

IR Camera Factors

Several instrumental factors to consider when performing IR testing include:

  • The distance between the component and the IR camera
  • Spatial resolution output (i.e. clarity of component)
  • Thermal resolution output (i.e. clarity of temperature differences)
  • Thermal range (i.e., ability to detect temperatures of the component being tested)
Industry Applications

IR thermography is utilized in many industries and applications. In the oil and gas and chemical processing industries, for example, thermography can be used to detect piping insulation issues, fluid levels, or identify trouble spots where rotating equipment is experiencing too much friction. Furthermore, IR testing is commonly used to locate hot spots and anomalies such as voids and inclusions. The benefits of IR testing include extended equipment life, decreased unscheduled shutdowns, reduced risk of equipment failure, and increased performance.
